- Hign-concerned Chemical: None
- Brand Name: NoEnName_Null
- Origin: Mainland China
- Certification: CE
- Product Type: toilet tissue paper rewinding machine
- processing type: Paper Folding Machine
- place of origin: Henan, China
- brand name: YG
- voltage: 220/380V
- power(w): 7.5kw
- dimension(l*w*h): 6.5m*2.7m*1.75m
- warranty: 1 Year
- production capacity: 30sets/month
- machinery test report: Provided
- video outgoing-inspection: Provided
- core components: PLC, motor, Pump
- Name: Toilet Paper Rewinding Machine
- Finished Products: TOILET ROLLER PAPER
- Application: Packing Industry
- Machine type: Paper Processing Machine
- Drive way: Electric Motor
- Speed: 800-1000 Pcs/min
- Automation: Fully Atuomatic
- Production: toilet paper
- Item: Mini Toilet Paper Making Machine
- Function: Embossing Folding Counting Cutting
- Condition: New
- Marketing Type: New Product 2020
- Warranty of core components: 1 Year
- Weight: 2000 kg
Hot sale toilet paper embossing printing rewinding cutting and sealing line
Toilet paper converting machine is widely used in toilet paper shaft, non-woven fabric, air-laid paper cutting rewinding, slitting width, layer number can be adjusted according to need, quick speed, stable running, simple operation, is the paper mill or cutting and ideal facilities for the production of paper products plant. this rewinding machine can be with embossing roller and paper tube feeder.we are factory for toilet paper rewinding machine, rewinding slitting machine, toilet paper converting machine,toilet paper roll making machine, toilet paper roll cutting machine, toilet paper roll packing machine, napkin paper machine,tissue paper machine and so on.
|
Machine Model
|
1092/1575/1880/2100/2400
|
|
Paper Width(mm)
|
1092mm/1575mm/1880mm/2100mm/2400mm
|
|
Paper Diameter(mm)
|
φ1200mm(Please Specify)
|
|
Paper Core Inner Diameter
|
φ76mm(Please Specify)
|
|
Product Diameter
|
φ40mm-200mm
|
|
Paper Backing
|
1-4layer,general chain feed or continuously variable transmission feed paper
|
|
Punch
|
2-4 Knife,Spiral Cutter Line
|
|
Hole Pitch
|
Positioning of Belt and Chain Wheel
|
|
Control System
|
PLC Control,Variable Frequency Speed Control,Touch Screen Operation
|
|
Product Range
|
Core Paper,Non Core Roll Paper
|
|
Drop Tube
|
Manual,Automatic(Optional)
|
|
Non core roll paper
|
automtic core pulling
|
|
Production Speed
|
150-280m/min
|
|
Spray,Cutting and Rewinding
|
Automtic
|
|
Finished product launch
|
Automtic
|
|
Point Moving Mode
|
Before and After the Point Moving
|
|
Power Configuration
|
380V50HZ
|
|
Required air pressure
|
0.5Mps(The Self)
|
|
Embossing
|
Single Embossing,Double Embossing(Steel Roller to Wool Roller,Steel Roller)Optional
|
|
Blank Holder
|
Airbag Control,Cylinder Control,Steel to Steel Structure
|
|
Outline Dimension
|
6200mm-7500mm*2600mm-3200mm*1750mm
|
|
Machine Weight
|
2900KG-3800KG
|
